Stratus SRC series "Gen 2" rocking piston compressors are specifically designed for the demanding job of 24 hour operation. They are ideal for pond aeration systems. The oil-less design safely aerates ponds with no electricity in the water. The shore mounted compressor sends air through tubing to a bottom mounted diffuser for a safe, effective way to aerate ponds. Compressors are available in 115v or 230v.
* Inlet air filter, rubber foot pads and 5' power cord included
* Universal dual voltage motor
* Includes Stratus Smart-Start technology
* Oil-less operation
* Superior quality, flexible cup material for increased reliability
* Die-cast aluminum components for overall strength
* Hard coated cylinder for wear resistance
* Permanently lubricated bearings
* 2 year limited warranty
* Assembled in the USA
Use for:
Read more
Ship Weight: 22 lbs
Horsepower
1/2 HP
Volt/Hz (Select Proper Voltage When Ordering)
115V/60Hz
230V/60Hz
Motor Type
4 Pole
Maximum Air Flow
4.5 CFM
| Output: Depth(ft) | CFM |
| 0 | 4.50 |
| 5 | 4.35 |
| 10 | 4.10 |
| 15 | 3.90 |
| 20 | 3.69 |
| 25 | 3.50 |
| 30 | 3.30 |
Inlet Size
1/4"
Outlet Size
1/4"
Amps (At 10' Operating Depth)
115V: 3.6 amps
230V: 1.8 amps
Max PSI
30
Noise Level
<65 dB
Power Cord Length
5'
Warranty
2 year
Read more
Stratus SRC series "Gen 2" rocking piston compressors are specifically designed for the demanding job of 24 hour operation. They are ideal for pond aeration systems. The oil-less design safely aerates ponds with no electricity in the water. The shore mounted compressor sends air through tubing to a bottom mounted diffuser for a safe, effective way to aerate ponds. Compressors are available in 115v or 230v.
