Orb-3 Aeration Eclipse EC110 Diffuser

SKU: M522-000-1E
Type: Aeration Diffusers
$437.75

The Eclipse EC110 water diffuser checks all the boxes! Sturdy design, simple assembly and energy-efficiency are what makes this aerator a solid choice.

This American made diffuser includes a stainless steel weighted base, microporous aeration membrane, built-in check valve, hose barbs for 3/8" or 1/2" air line, tagline tie off spot and smooth handle for easy retrieval. No extra fittings required.

The Eclipse EC110 is engineered to have a high CFM capacity with low back-pressure. It’s flat-packed so it ships economically making this powerful fine bubble diffuser a smart choice. Choose the Eclipse EC110 diffuser for a new aeration system or to upgrade diffusers in an older system.

Basic Assembly required.

Notify me when back in stock

Use for:

  • Diffuser / Aerator
  • Turnover / Mixing

Features

  • 72 inches of anti-fouling; microporous aeration tubing
  • Built-in check valve
  • Corrosion resistant stainless steel base & hardware
  • Strain-relief clamp with built-in hose barbs for 3/8" or 1/2" air line
  • Built-In handle
  • Easy to assemble, install, retrieve and maintain
  • Produces 2-3mm bubbles for maximum aeration efficiency
  • Works with any compressor sized to deliver desired SCFM and PSI
  • For use in lakes, retention ponds, wastewater lagoons and treatment basins
  • Basic Assembly is required

Read more Read Less

feature_image
faq-img

Specification

SCFM Range

2.0 - 10.0

Minimum Depth

4 feet

Construction

Stainless steel base & hardware

Fitting Size

3/8" or 1/2" MNPT

Requirements

  • 3/8" or 1/2" airline
  • Compressor sized to deliver desired PSI and SCFM

Minimum Operating Depth

4 feet

Active Surface Area

192 sq in

Linear Lift

144"

Flow Interference

1.0"

Warranty

5 years

Read more Read Less

FAQ

What types of water does this diffuser work in? + -

The Eclipse diffusers are unaffected by Salt-Sater, Brackish Water or Frac Flowback.

Do I need a separate air pump for this? + -

Yes, in addition to the diffuser you will need at minimum a compressor and air line to get from the compressor to the diffuser

Description

The Eclipse EC110 water diffuser checks all the boxes! Sturdy design, simple assembly and energy-efficiency are what makes this aerator a solid choice.

This American made diffuser includes a stainless steel weighted base, microporous aeration membrane, built-in check valve, hose barbs for 3/8" or 1/2" air line, tagline tie off spot and smooth handle for easy retrieval. No extra fittings required.

The Eclipse EC110 is engineered to have a high CFM capacity with low back-pressure. It’s flat-packed so it ships economically making this powerful fine bubble diffuser a smart choice. Choose the Eclipse EC110 diffuser for a new aeration system or to upgrade diffusers in an older system.

Basic Assembly required.
